Model | PA10500 | PA20300 | PA30200A | PA30250 | PA50120 | PA-6100 | PA20030 |
DC output | Voltage | 0-10V | 0-20V | 0-30V | 0-30V | 0-50V | 0-60V | 0-200V |
Current | 0-500A | 0-300A | 0-200A | 0-250A | 0-120A | 0-100A | 0-30A |
Ripple and accuracy | Ripple | 0.5%+10mV | 0.3%+10mV |
Accuracy | Voltage:0.3%+10mVCurrent:0.3%+10mA | Voltage:0.2%+10mV Current::0.3%+10mA |
Model | PA30020 | PA60010 | PA10005 | PA15500 | PA60150 | PA90100 | PA15060 |
DC output | Voltage | 0-300V | 0-600V | 0-1000V | 0-15V | 0-60V | 0-90V | 0-150V |
Current | 0-20A | 0-10A | 0-5A | 0-500A | 0-150A | 0-100A | 0-60A |
Ripple and accuracy | Ripple | 0.3%+10mV |
Accuracy | Voltage:0.2%+10mV Current:0.3%+10mA |
Model | PA20045 | PA30030 | PA60015 | PA10008 | PA20003 | PA30002 |
DC output | Voltage | 0-200V | 0-300V | 0-600V | 0-1000V | 0-2000V | 0-3000V |
Current | 0-45A | 0-30A | 0-15A | 0-8A | 0-3A | 0-2A |
Ripple and accuracy | Ripple | 0.3%+10mV |
Accuracy | Voltage:0.2%+10mV Current:0.3%+10mA |
A type | B type |
AC INPUT | 7.5KW lower than 220V±10%/7.5KW higher than 380V±10% |
Output display | 4 digit table Accuracy:±1% +1 bytes | LCD display Accuracy:±1% +1bytes |
| Power, Resistance display |
Display format:00.00V-99.99V;000.0V-999.9V;0000V-9999V;0.000V-9.999V |
Panel locking function | | Panel locking |
Voltage setting and preset | 10-Ring Potentiometer/Rotary Encoder | Rotary Encoder |
Current setting and preset | 10-Ring Potentiometer/Rotary Encoder | Rotary Encoder |
Over voltage protection | Adjustable protection value at rated 0-10% , turn off output after protection, reboot when unlock | Setting over voltage protection |
Over current protection | Overload, short-circuit, fixed current output | Setting over current protection |
Temperature protection | Built-in O.T.P protection, protection value is 85?±5% (heatsink temperature), turn off the output after protection |
Output and heat dissipation | Output positive(+),negative (-)can be arbitrarily grounded; heat dissipation method: Forced air cooling |
Temperature environment | Operation environment:0?~40?;Humidity:10%~85%RH;Storage environment:temperature:-20?~70?;Humidity:10%~90%RH |
